Remote control fire water monitor system consists of electronic control fire water monitor, control panel, electric valve, control systems (remote centralized control, on-site wired control, wireless remote control) and water supply systems.
Remote control fire water monitor has two DC drive control methods, electric wired and wireless remote control. When the water jet is sprayed, remote control fire water monitor can extinguish solid fires. When spraying blooming water mist, remote control fire water monitor can be used for cooling and fire fighting.
Remote control fire water monitor is a fire fighting equipment that enables the operator to directly control the shooting angle of the fire water monitor at a long distance, and can well protect the personal safety of fire extinguishers.
▶ Self-control: The fixed fire monitor has its own control panel. When there is no external controller, the fire monitor can be controlled through its own control panel.
▶ Wire control: The on-site control box can be connected via wired, and the state of the fire monitor can be controlled through the on-site control box. The farthest control distance is ≥1km, which can realize 1 control 1 or 1 control multiple.
▶ Remote control: The state of the fire monitor can be controlled wirelessly through the remote control. The remote control radius is ≥150m, which can realize 1 control 1 or 1 control multiple.
▶ Linkage host: The fire monitor can be remotely controlled in the fire control room through the linkage host.
Various spraying methods:
▶ Columnar spraying method: the water shape of the fire monitor spray is columnar, which has concentrated water volume, long range and fast fire extinguishing.
▶ Mist spraying method: The water spray of the fire monitor is in the form of mist, and the water volume of the water is dispersed and the fire extinguishing area is large.
▶ Automatic display method: The fire monitor has an automatic display function. There are vertical furnishings, horizontal furnishings, and composite furnishings. Users can choose different display methods according to the actual situation on site, or set different display angles according to actual needs.
| Model | PSKD30-JXP | PSKD40-JXP | PSKD50-JXP |
| Rated Flow | 1800LPM | 2400LPM | 3000LPM |
| Protection Radius | 55m | 60m | 65m |
| Working Pressure | 0.8MPa | Pitching Angle | ﹣15°~60° |
| Flange | DN65 | Horizontal Rotating Angle | 360° |
